Chapter 2: Maintenance and Component Installation
76.20 mm
76.20 mm
420 mm
2. Decide on an orientation to mount the server. The server can only be mounted with the
I/O panel facing left or right.
Figure 2-15. Possible Mounting Orientations
76.20 mm
76.20 mm
420 mm
I/O Facing Left
I/O Facing Right
