Supermicro X11DPG-QT User Manual

Note: The table above is continued on the next page.
16
Super X11DPG-QT User's Manual
Motherboard Features
I/O Devices
• Serial (COM) Port • One Fast UART 16550 port on the I/O back panel
• SATA 3.0
• Eight SATA 3.0 connections supported by Intel PCH (I-SATA0~3, I-SATA4~7)
• Two SATA 3.0 ports with power-pin built-in, w/support of Supermicro SuperDOM
(S-SATA4, S-SATA5)
• RAID (PCH) • RAID 0/1/5/10 (RSTe 5.x)
Peripheral Devices
• Two USB 3.0 ports on the rear I/O panel (USB4, USB5)
• One internal USB 3.0 header with two (2) USB connections on the motherboard for front access (USB6, USB7)
• One Type A USB 3.0 connector for front access (USB8)
• Two USB 2.0 ports on the rear I/O panel (USB0, USB1)
• One internal USB 2.0 header with two USB connections on the motherboard for front access (USB2, USB3)
BIOS
• 32MB SPI AMI BIOS
®
SM Flash UEFI BIOS
• ACPI 3.0/4.0, USB keyboard, Plug-and-Play (PnP), SPI dual/quad speed support, riser-card auto detection support, and
SMBIOS 2.7 or later
Power Management
• Main switch override mechanism
• Power-on mode for AC power recovery
• Intel Intelligent Power Node Manager 4.0 (Available when the Supermicro Power Manager [SPM] is installed and a special
power supply is used.)
• Management Engine (ME)
System Health Monitoring
• Onboard voltage monitoring for +3.3V, 3.3V standby, +5V, +5V standby, +12V, CPU core, memory, chipset, BMC, and
PCH voltages
• CPU System LED and control
• CPU Thermal Trip support
• Status monitor for on/o󰀨 control
• CPU Thermal Design Power (TDP) support of up to 205W (See Note 1 on the next page.)
Fan Control
• Fan status monitoring via IPMI
• Dual cooling zone
• Multi-speed fan control via onboard BMC
• Pulse Width Modulation (PWM) fan control

Supermicro X11DPG-QT Specifications

General

PS/2 ports quantity	0
IPMI LAN (RJ-45) port	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Number of SATA III connectors	10
Number of DIMM slots	16
Maximum LRDIMM memory	2000 GB
Supported RDIMM module capacity	64GB
Memory voltage	1.2 V
Supported memory types	DDR4-SDRAM
Supported memory clock speeds	2133, 2400, 2666 MHz
BIOS type	AMI
ACPI version	4.0
BIOS memory size	64 Mbit
RAID levels	0, 1, 5, 10
Wi-Fi	No
LAN controller	Intel® X550
Ethernet interface type	10 Gigabit Ethernet
On-board graphics card model	Aspeed AST2500
Bundled software	Intel Node Manager, IPMI2.0, KVM LAN, NMI, SPM, SSM, SUM, SuperDoctor 5, Watchdog
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
Supported QPI	10.4 GT/s
Processor socket	LGA 3647 (Socket P)
Processor manufacturer	Intel
Processor number of cores supported	28
Component for	Server
Motherboard chipset	Intel® C621
Audio output channels	7.1 channels
PCI Express x16 (Gen 3.x) slots	6

Weight and Dimensions

Depth	335.3 mm
Width	384 mm
