Supermicro X11DPG-QT User Manual

Note: The table above is continued on the next page.
15
Chapter 1: Introduction
Motherboard Features
CPU
• Dual Intel Xeon Scalable-SP and 2nd Gen Intel Xeon Scalable-SP processors (Socket P) with three Intel UltraPath
Interconnect (UPI) links of up to 10.4 GT/s
Note: For the latest CPU/memory updates, please refer to our website at http://www.supermicro.com/products/
motherboard.
Memory
• Integrated memory controller embedded in the processor supports up to 4TB of 3DS Load Reduced DIMM (3DS LRDIMM),
3DS Registered DIMM (3DS RDIMM), or up to 2TB of Load Registered DIMM (LRDIMM), with speeds of 2933*/2666/24
00/2133/1866/1600/1333 MHz modules in 16 memory slots
Notes: 1. The memory capacity support will di󰀨er according to the processor SKUs. 2. Up to 2TB DCPMM memory
is supported (2nd Gen Intel Xeon Scalable-SP 82xx/62xx/52xx/4215 series processors only). 3. Support for 2933
MHz memory is dependent on the CPU SKU. 4. Refer to Chapter 2 for detailed DDR4 memory support list.
DIMM Size
• Up to 256GB at 1.2V
Note 1: Memory speed support depends on the processors used in the system.
Note 2: For the latest CPU/memory updates, please refer to our website at http://www.supermicro.com/products/
motherboard.
Chipset
• Intel C621
Expansion Slots
• Four PCIe 3.0 x16 slots supported by CPU1 (CPU1 Slot2, CPU1 Slot4) and CPU2 (CPU2 Slot6, CPU2 Slot8)
• Two PCIe 3.0 x16 or HSSI (High Speed Serial Interface) supported by CPU1 (CPU1 Slot9) and CPU2 (CPU2 Slot10)
(Note: Motherboard R1.10A and later do not support HSSI on Slot9 and Slot10.)
• One PCIe 3.0 x4 in x8 slot supported by CPU2 (CPU2 Slot11)
Non Volatile Memory Express (NVMe) Slot
• One PCIe 3.0 x4 M.2 slot
• M.2 Form Factor: 2280, 22110
• M.2 Key: M-Key
BaseBoard Management Controller (BMC)
• ASPEED AST2500 Baseboard Controller (BMC) supports IPMI 2.0
• One IPMI_dedicated_LAN port located on the rear I/O back panel
Graphics
• Graphics controller via AST2500 BMC
Motherboard Features

Supermicro X11DPG-QT Specifications

General

PS/2 ports quantity	0
IPMI LAN (RJ-45) port	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Number of SATA III connectors	10
Number of DIMM slots	16
Maximum LRDIMM memory	2000 GB
Supported RDIMM module capacity	64GB
Memory voltage	1.2 V
Supported memory types	DDR4-SDRAM
Supported memory clock speeds	2133, 2400, 2666 MHz
BIOS type	AMI
ACPI version	4.0
BIOS memory size	64 Mbit
RAID levels	0, 1, 5, 10
Wi-Fi	No
LAN controller	Intel® X550
Ethernet interface type	10 Gigabit Ethernet
On-board graphics card model	Aspeed AST2500
Bundled software	Intel Node Manager, IPMI2.0, KVM LAN, NMI, SPM, SSM, SUM, SuperDoctor 5, Watchdog
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
Supported QPI	10.4 GT/s
Processor socket	LGA 3647 (Socket P)
Processor manufacturer	Intel
Processor number of cores supported	28
Component for	Server
Motherboard chipset	Intel® C621
Audio output channels	7.1 channels
PCI Express x16 (Gen 3.x) slots	6

Weight and Dimensions

Depth	335.3 mm
Width	384 mm
