Super X11DPG-QT User's Manual
Connector Description
JSD1, JSD2 SATA DOM Power Connectors 1/2
JSEN1 Inlet Sensor Header
JSPDIF_IN1 Sony/Philips Digital Interface Audio Input Header
JSTBY1 Standby Power Connector
JTBT1 General Purpose Header for Thunderbolt Add-on Card
JTPM1 Trusted Platform Module/Port 80 Connector
JUIDB1 UID (Unit Identier) Switch
LAN1, LAN2 LAN Ports
M.2 CONNECTOR
PCIe M.2 Connector, small form factor devices and other portable devices for high speed NVMe
SSDs
S-SATA4, S-SATA5 SATA 3.0 Ports with Power-pin Built-in w/ support of SuperDOM (Device-On Module)
S-SGPIO Serial Link General Purpose I/O Header
SP1 Internal Speaker/Buzzer
USB0, USB1 Back Panel USB 2.0 Ports
USB2, USB3 Front Access USB 2.0 Header
USB4, USB5 Back Panel USB 3.0 Ports
USB6, USB7 Front Access USB 3.0 Header
USB8 USB 3.0 Type A Header
VGA VGA Port (Back Panel)
LED Description Status
LED2 UID (Unit Identier) LED Solid Blue: Unit Identied
LEDM1 BMC Heartbeat LED Blinking Green: BMC Normal
LEDPWR Onboard Power LED Solid Green: Power On
Note: To avoid causing interference with other components, please be sure to use an
add-on card that is fully compliant with the PCIe standard on a PCIe slot.
