X9DA7/X9DAE Motherboard User's Manual
Warning: To prevent damage to the power supply or motherboard, please use a power
supply that contains a 24-pin and two 8-pin power connectors. Be sure to connect
these power supply connectors to the 24-pin power connector (J22) and two 8-pin
power connectors (JPWR1, JPWR2) on the motherboard. Failure in doing so will void
the manufacturer warranty on your power supply and motherboard.
(L-)SAS 0~3, 4~7 Serial_Attached SCSI 2.0 Connections 0~3, 4~7 from the LSI SAS Control-
ler (X9DA7 Only)
(I-)SATA0~3 Intel SB SATA Connectors 0~3 (SATA 0/1: SATA 3.0 Ports, SATA2/3: SATA
2.0 ports)
(S-)SATA0~3 SATA 2.0 Connectors 0~3 from Intel SCU (Storage Control Unit)
SP1 Onboard Buzzer (Internal Speaker)
STBY1 Standby Power Header
S-SGPIO 1 Serial-Link General_Purpose IO -Header for S-SATA Connections 0~3
T-SGPIO 1 Serial-Link General_Purpose IO Header for I-SATA Connections 0~3
USB 2.0 0~3 Back Panel USB 2.0 Ports 0/1/2/3
USB 2.0 4 Front-Panel Accessible Type A USB 2.0 Header (USB 4: J25)
USB 2.0 5/6 Front-Panel Accessible USB 2.0 Connections 5/6
USB 3.0 0/1 Back Panel USB 3.0 Ports 0/1
USB 3.0 2/3 Front-Panel Accessible USB 3.0 Connections 2/3
X9DA7/X9DAE LED Indicators
LED Description State Status
DS1 SAS LED (Reserved for Internal Use)
LE1 Standby PWR LED Green: On SB Power On
