Supermicro X9DA7 User Manual

Chapter 1: Overview
1-7
Motherboard Features
CPU
• Dual Intel
®
E5-2600(v2) Series Processors (Socket
R LGA 2011); each supports two full-width Intel
QuickPath Interconnect (QPI) links of up to 8.0 GT/s
per QPI link).
Note: For Intel E5-2600(v2) processor support,
BIOS version 3.0 or above is required.
Memory
• Integrated memory controller supports up to 1 TB
of Load Reduced (LRDIMM), 512 GB of Registered
(RDIMM) or 128 GB of Unbuffered (UDIMM) ECC/
Non-ECC DDR3 800/1066/1333/1600/1866 MHz
240-pin 4-channel memory modules in 16 DIMM
slots.
Note 1: 1866 MHz memory support is depen-
dent on Intel E5-2600v2 CPUs.
Note 2: For the latest memory updates, please
refer to the Tested Memory List posted on our
website (http://www.supermicro.com/products/
motherboard).
Chipset
• Intel® C602 Chipset (PCH J)
Expansion
• Three (3) PCI-Express 3.0 x16 slots (CPU1 Slot1/
Slot3, CPU2 Slot5),
• Two (2) PCI-E3.0 x8 slot (CPU2 Slot4/Slot6),
• One (1) PCI Express 3.0 x 4 in x8 slot (CPU2 Slot2)
Slots
Network
• One i350 Dual-Channel Gigabit (100/1000 Mb/s)
Ethernet Controller for LAN 1/LAN 2 ports.
• LSI 2308 SAS Controller
SATA Connections
• SATA Ports • Two (2) SATA 3.0 Ports: I-
SATA 0/1,
• Two (2) SATA 2.0 Ports (I-
SATA 2/3 from Intel PCH),
• Four (4) SATA 2.0 Ports (S-
SATA 0~3) from Intel SCU
• RAID RAID 0, 1, 5, 10 (Windows/
Linux latest kernel)

Supermicro X9DA7 Specifications

General

Microphone in	Yes
PS/2 ports quantity	2
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 2.0 connectors	3
Integrated SAS ports	8
Number of SATA II connectors	6
Maximum UDIMM memory	128 GB
Number of DIMM slots	16
Supported RDIMM clock speeds	800, 1066, 1333, 1600 MHz
Supported DIMM module capacities	16GB, 1GB, 2GB, 32GB, 4GB, 8GB
PCI Express slots version	3.0
Memory voltage	1.35, 1.5 V
Maximum RDIMM memory	512 GB
Supported memory types	DDR3-SDRAM
BIOS type	AMI
ACPI version	4.0
BIOS memory size	128 Mbit
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	Serial Attached SCSI (SAS)
Wi-Fi	No
LAN controller	Intel® I350
Ethernet interface type	Gigabit Ethernet
Cables included	FireWire, SATA
Bundled software	SuperDoctor® III Watch Dog, NMI
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
Supported QPI	6.4, 7.2, 8 GT/s
Processor socket	LGA 2011 (Socket R)
Intel Xeon series	E5-2600
Processor manufacturer	Intel
Processor thermal power (max)	150 W
Processor number of cores supported	4, 6, 8
Component for	Workstation
Motherboard chipset	Intel® C602
Audio output channels	7.1 channels
Motherboard form factor	Extended ATX
Sustainability certificates	RoHS

Weight and Dimensions

Depth	332 mm
Width	305 mm
