1-8
X9DA7/X9DAE Motherboard User's Manual
Peripheral
Devices
USB Devices (11 USB Connections)
• Four (4) USB 3.0 ports: USB 3.0 Ports 0/1 (on the
I/O Backplane), USB 3.0 USB 2/3 (close to SAS ports
for front access),
• Seven (7) USB 2.0 Connections:
•Four (4): Backplane USB 2.0 (Ports 0~3)
•Two (2): Front-Accessible USB (USB 5/6), and
•One (1) Type A USB Header (USB 4, located at
J25) for front USB access
I/O Devices
Serial (COM) Port
• One (1) Fast UART 16550 Connection: 9-pin RS-232
Serial Port
Keyboard/Mouse
• One PS2 Keyboard/Mouse Connector on the I/O
Backpanel
Audio
• ALC 889 Audio Controller
• Backpanel 7.1 High Denition Audio
• Front Panel Audio Header (J18)
• SPDIF_In/SPDIF_Out (Sony_Philips Digital Inter-
face)_In/Out Headers
Power Con-
nectors
ATX Power Connectors & DOM Power Con-
nector
• One (1) 24-pin Main Power (J22)
• Two (2) 8-pin CPU PWR Connectors (JPWR1/2)
• DOM (Disk_On_Module) Power Connector for Se-
rial_link devices (JSD1)
Super I/O
Super I/O
• Winbond W83627
BIOS
• 16MB AMI BIOS
®
Flash EEPROM
• APM 1.2, DMI 2.3, PCI 2.3, ACPI 1.0/2.0/3.0, USB
Keyboard, Plug & Play (PnP) and SMBIOS 2.3
SAS Connections (X9DA7 Only)
• SAS Ports • Eight (8) SAS 2.0 Ports: SAS 0~3, 4~7 from LSI
SAS Controller
• RAID RAID 0, 1, 10
