Chapter 1: Introduction
1-5
C7P67 Headers/Connectors
Connector Description
Audio_FP Front Panel Audio Header
HD Audio High-Defi nition Audio Connector
B1 Onboard Battery
COM1/COM2 COM1/2 Serial Connection Headers
BIOS AMI SPI BIOS
Fans 1~4, Fan A System/CPU Fan Headers (Fan1: CPU Fan)
J15/J18 IEEE 1394_1 (J15)/1394_2 (J18) Headers
JCPUVRD SMB CPU Overclocking SMB(System_Management_Bus) Header (Note)
IDE IDE Connector Header
JD1 Speaker/buzzer (Pins 1-2: Buzzer, Pins 1~4: External Speaker)
JF1 Front Panel Control Header
JL1 Chassis Intrusion Header
JLED Power LED Indicator Header
JPW1 24-pin ATX Main Power Connector (Required)
JPW2 +12V 8-pin CPU power Connector (Required)
KB/Mouse Keyboard/Mouse Connectors
LAN1/LAN2 Gigabit (RJ45) Ports (LAN1/2)
JSPDIF_In/JSPDIF_OUT SPDIF_(Sony/Philips Digital Interface)_In/ SPDIF_Out Headers
JTPM1 Trusted Platform Module (TPM)/80 Port Header
JWF1 SATA DOM (Device_On_Module) Power Connector
JWOL Wake_On_LAN Header
JWOR Wake_On-Ring Header
Slot1/Slot2 PCI 33 MHz Slots
Slot3/Slot5/Slot7 PCI-Express 2.0 x1 Slots
Slot4 PCI-Express 2.0 x8 in x16 Slot
Slot6 PCI-Express 2.0 x16 Slot
(I-)SATA (3.0) 0/1, (2.0) 2~5 (Intel) Serial ATA 3.0 Ports 0/1. Serial ATA 2.0 2~5
(M-)SATA (3.0) 0/1 (Marvel) Serial ATA 3.0 Ports 0/1
SP1 Internal Buzzer
USB (2.0) 0/1, 8/9, 11/12, 13/10 Backpanel USB 2.0 Ports 0/1, 8/9, 11/12, 13/10
USB (3.0) 0/1 Backpanel USB 3.0 Ports 0/1
USB2/3, USB4/5 Front Accessible USB Connections 2/3, 4/5
C7P67 LED Indicators
LED Description Color/State Status
LED1 Onboard Standby PWR LED Green: Solid on Power On
