7. Flush mounting
5.
Use the provided mounting holes.
6.
Mounting holes (if required).
Two mounting holes are required to
fasten the belt winder. Generally, it is
possible to make use of the existing
installation holes to screw the belt
winder in place.
If this is not the case, push the belt
winder into the belt box and draw
on the required mounting holes;
otherwise continue with point 7.
NOTE
Pay attention to the hole spacing for
the ush-mounted device.
Then, pull the belt winder out of the
belt box and drill the mounting holes
with a 6 mm masonry drill bit.
Subsequently place the provided
mounting plugs into the holes drilled.
