Chapter 7 Display Functions
www.supmea.com
-54-
7.3.1. Registered Address
Communication data and register address are in the following table.
Parameter
Type
Address
Explanation
Real-time flow rate
float
100
Real-time flow velocity
float
102
Flow percentage
float
104
50 stands for 50%
Electric conductivity
float
106
Forward flow
accumulation of
integer
ulong
108
Forward flow
accumulation of
decimal
ulong
110
The decimal part magnifies
by 100 times, 123 stands for
0.123
Reverse flow
accumulation of
integer
ulong
112
Reverse flow
accumulation of
decimal
ulong
114
The decimal part magnifies
by 1,000 times 123 stands
for 0.123
Note: Float/ulong/long type data, Communication transmission is in byte
order2-1-4-3; ushort type data transmission is in accordance with 2-1.
