SUPMEA SUP-LDG User Manual

Chapter 8 Technical parameters
www.supmea.com
-56-
Chapter 8 Technical Parameters
8.1. Technical Parameters
Measuring System
Execution Standard
JB/T9248-2015
Measuring principle
Faraday's law of electromagnetic induction
Function
Real-time flow rate, flow velocity, mass flow (when the
density is constant), real-time measurement and flow
accumulation
Module configuration
Measurement system is made up of signal converter and
measurement sensor
Converter
Compact Type
IP65
Remote Type
IP65(IP68 optional)
Measurement sensor
Nominal Diameter
DN15-DN1000
Flange
In line with GB/T9119-2000 standard carbon steel (Optional
stainless steel flanges), other standard flange can be
customized
Pressure rating
(High pressure can be
customized)
DN6 - DN80, PN<4.0MPa
DN100 - DN150, PN<1.6MPa
DN200 – DN1000, PN<1.0MPa
DN1200 – DN2000, PN<0.6MPa
Lining Material
Chloroprene rubber (CR),
Polytetrafluoroethylene (PTFE/F4),
Fluorinated ethylene propylene (FEP/F46),
Teflon(PFA)
Electrode Material
316L Stainless Steel, Hastelloy C, Hastelloy B, Ti, Ta, Pt
IP Rate
IP68
IP65
Medium temperature
-25 – 180
℃
-10 – 80
℃
Buried depth
Less than 5 meters
(only IP68 protection of remote type sensor)
Immersion depth
Less than 3 meters
(only IP68 protection of remote type sensor)
Sensor cable
Only for remote type, the standard 10m cable; other cables
suggest custom no longer than 20 meters.
