SUPMEA SUP-LDG User Manual

Chapter 8 Technical parameters
www.supmea.com
-60-
8.3. Flowmeter
Flowmeter
Nominal Diameter
(mm)
Flow range (m
3
/h)
10
0.02827-0.25
0.3-1.6
2.0-3.3924
15
0.0636-0.6
0.8-3.0
4.0-7.632
20
0.131-1.0
1.2-5.0
6.0-13.6
25
0.176-1.6
2.0-8.0
10-21
32
0.2895-2.5
3.0-12
16-35
40
0.4524-4.0
5.0-20
25-45
50
0.707-6.0
8.0-40
50-85
65
1.195-10
12-60
80-143
80
1.81-16
20-120
160-217
100
2.83-25
30-160
200-339
125
4.42-40
50-250
300-530
150
6.36-60
80-400
500-763
200
11.3-100
120-600
800-1357
250
17.7-160
200-800
1000-2120
300
25.45-250
300-1200
1600-3054
350
34.6-300
400-1600
2000-4157
400
45.2-400
500-2000
2500-5429
450
57.3-500
600-2500
3000-6871
500
70.7-600
800-3000
4000-8482
600
102-800
1000-4000
5000-12216
700
139-1200
1600-5000
6000-16620
800
181-1600
2000-6000
8000-21720
900
229-1600
2000-8000
10000-27480
1000
283-2000
2500-10000
12000-33924
1200
407-2500
3000-12000
16000-48833
1400
554-3000
4000-16000
20000-66468
1600
723-4000
5000-20000
27000-86815
Reduction formula: (Flow )Q = (flow velocity) V×π×(DN/2)
2
,Unit: m/s and
m
3
/h
