NICE3000 User Manual Structure of the control system and the component introduction
49
Floor address settings:

Button stroe, there is storing buttons on the board.
Power supply and communication input terminal (CN1):

White, horizontal blocks with 3.96 gap distance, user need to prepare the terminal head.
GND
MP 2 4
1
3
4
2
MO D +
MO D -
Ordinary button input terminal JP1-6
MP 2 4
KEY- I N
KEY- LED
1
3
4
2
1
3
4
2
1 and 2 are 24V3 is button input terminal4 is button light output
3.3.6 MCTC-HCB-N
In order to meet the customer needs for the thin display board, Monarch developed a ultrathin
display board with a thickness of 10mm, see Fig 3-9-15 for the appearance.
Product photo 1)
Fig 3-9-15 MCTC-HCB-N
