Function parameter description NICE3000 User Manual
104
Function
code
Name Default Min. Unit Setting Range
F1-01 Rated power
Depending on
the model
0.1kW 1.175.0kW
F1-02 Rated voltage 380V 1V 0440V
F1-03 Rated current
Depending on
the model
0.01A 0.00655.00A
F1-04 Rated frequency 50.00Hz 0.01Hz 0.0099.00Hz
F1-05 Rated rotation speed 1460rpm 1rpm 03000rpm
Please set according to the nameplate parameters of the motor.
The system has motor parameter auto-tuning function. Only whe
n the motors parameter is
setting correctly can the system complete parameter tuning function correctly to fulfill good
vector control function.
Function
code
Name Default Min. Unit Setting Range
F1-06
Stator resistance
(Asynchronous motor)
Depending on
the model
0.001Ω 0.00030.000Ω
Encoder initialized angle
(Synchronous motor)
Depending on
the mode
0.1° 0359.9°
F1-07
Rotor
resistance(asynchronous)
Current angle(sync)
Depending on
the model
0.1
0.001Ω 0.00030.000Ω
F1-08
Leakage inductance
(Asynchronous motor)
Depending on
the model
0.01mH 0.00300.00mH
Wiring conne
ction
(Synchronous motor)
Depending on
the model
1 015
F1-09
Mutual inductance
Depending on
the model
0.1mH
0.13000.0mH
ADC sampling delay
function (sync)
0.0 0.1 0-40
F1-10
No-load current
Depending on
the model
0.01A
0.01300.00A
Selection check of
encoders signal
0.0 0.1 0-31
To ensure system performance, please set according to the system standard of the motor
arrangement. If the motor power is a lot different fr
om the standard motor power, the
performance of system control will decline.
The parameter F1-06 means different meaning when used in different motors. When its used
in asynchronous motor, it means the stator resistance. When its used in synchronous motor,
it means the encoder initialized angle. No matter which motor to be used in, this parameter can
be created after NICE3000 tuning. And users ca
n modify this parameter according to actual
condition.
If the automatic tuning of the motor is completed normally, the setup values in F1-F6 to F1-F10
will update automatically.
