Tube Serial
number
Tube passage
marker
Tube passage meaning Tube passage “light” meaning
4
A Door-open display output Door-open display light
B Door-close display output Door-close display light
C
Door-open delay display
output
Door-open delay display light
D Non-stop display output Non-stop display light
E Reserved
F Buzzer output Buzzer output availability
G Reserved
DP Energy saving Fan/light output availability
5
A System
light curtain state 1 Light curtain shut out
B System light curtain state 2 Light curtain shut out
C External call lock lift input Signal availability
D External call fire input Signal availability
E Full load Signal availability
F Over load Signal availability
F5-36
Weighing input selection Default 2 Min. Unit 1
Setting Range 0、1、2、3
0：Invalidation
1：Car top panel digital sampling.
2：Car top panel analog sampling.
3：Main control panel analog sampling.
F5-36 expresses signal channel of car weighing. Please exactly set this parameter before using
weighing device.
6.7 F6 Group Lift Basic Parameters
Function code Name Default Min. Unit Setting Range
F6-00 The highest landing 9 1 F6-01～31
F6-01 The lowest landing 1 1 1～F6-00
F6-02 Parking landing 1 1 F6-01～F6-00
When the system not in using time is over the F9-00 setting value, lift can return parking
landing by itself.
F6-03
Fire landing Default 1 Min. Unit 1
Setting Range The lowest landing(F6-01)～The highest landing(F6-00)
