6.14 FD Group Communication Parameters
Function code Name Setting Range Default Min. Unit
FD-00 Baud rate setting
0:300bps
1:600bps
2:1200bps
3:2400bps
4:4800bps
5:9600bps
6:19200bps
7:38400bps
5 1
FD-01 Data format
0: No check-out
1: Even check-out
2: Odd check-out
0 1
FD-02 Local address
0~127,0:
Broadcasting address
1 1
FD-03 Responding delay 0~20ms 10ms 1ms
FD-04
Communication
delaying time
0.0~60.0s ,0.0s:
invalidation
0.0s 0.1s
This group function codes can set NICE3000 RS232 Serial communication parameter for up bit
motor monitoring software communication. FD-00 sets Serial communication baud rate, FD-01
sets Serial communication data frames format, and FD-02 sets the local address of controller.
These parameters’ setting must be the same with the Serial communication parameters of
controller so that they can communicate normally. FD-03 sets the delaying tim
e of controller
transmitting data by the Serial port. FD-04 sets the overtime of the Serial port communication,
and the time of frame data transmitted must be within the time of FD-04 setting. Otherwise
communication error may occur.
6.15 FE Group Lift Function Setting Parameters
FE-00
Collective selective mode Default 0 Min. Unit 1
Setting Range 0、1、2
0:Full selective, lift responds to up call and down call.
1:Down selective, lift only responds to hall down call and doesn’t respond to hall up call.
2:Up selective, lift only responds to hall up call and doesn’t respond to hall down call.
