NICE3000 User Manual Function parameters tables
83
5.2 Function Parameters Tables
5.2.1 Groups of Function Parameters
Press UP/DOWN button after pressing “PRG”, all the first level menu displayed are the
groups of function. Details as follows:
F0——Basic parameters F9——Time parameters
F1——Motor parameters FA——Keyboard setting parameters
F2——Vector control parameters FB——Door function parameters
F3——Running control parameters FC——Protect function parameters
F4——Floor parameters FD——communication parameters
F5——Terminal function parameters FE——Lift function setting parameters
F6——Lift basic parameters FF——Factory parameters
F7——Testing function parameters FP——User parameters
F8——Reinforce function parameters
5.2.2 Parameters tables
Function
Code
Name Setting Range Min. Unit Default
Modifi-
cation
F0 Basic Parameters
F0-00 Control modes
0: Speed sensorless vector control(SVC)
1: Vector control(VC) with speed sensor
1 1 ★
F0-01
Command
source
selection
0：Operating panel command channel
1：Distance control
1 1 ★
F0-02
Operating panel
speed
0.050～F0-04 0.001m/s 0.050m/s ☆
F0-03
Elevator Max.
running speed
0.250～F0-04 0.001m/s 1.600m/s ★
F0-04
Elevator rated
speed
0
.250～4.000m/s 0.001m/s 1.600m/s ★
F0-05 Lift rated load 300～9999 kg 1 kg 1000 kg ★
F0-06 Max. frequency 20.00Hz～99.00Hz 0.01Hz 50.00Hz ★
F0-07
Carrier
frequency
0.5～16.0kHz 0.1kHz 6kHz ☆
F1 Motor Parameters
F1-00
Encoder type
selection
0: SIN/COS increment (ERN 1387)
1: UVW increment
1 1 ★
F1-01 Rated power 1.1～75.0kW 0.1kW
Depending
on the
model
★
F1-02 Rated voltage 0～440V 1V 380V ★
F1-03 Rated current 0.00～655.00A 0.01A
Depending
on the
mo
del
★
F1-04
Rated
frequency
0.00～99.00Hz 0.01Hz 50.00Hz ★
F1-05
Rated rotation
speed
0～3000rpm 1 rpm 1460 rpm ★
