and motor of the lift. The parameter F0-03 means the actual speed within the speed range of
F0-04.
For example: One lift rated speed is 1.750 m/s, but the actual Max.speed is 1.720 m/s. So
F0-03 = 1.720 m/s; F0-04 = 1.750 m/s.
F0-05
Lift rated load Default 1000kg Min. Unit 1kg
Setting Range 300～9999kg
It can set the rated load of lift. This code is used for anti-nuisance function.
F0-06
Max. frequency Default 50.00Hz Min. Unit 0.01Hz
Setting Range 20.00～99.00Hz
It can set Max. Frequency of system output and the frequency must be higher than rated
frequency of the motor.
F0-07
Carrier frequency Default 6kHz Min. Unit 0.1kHz
Setting Range 0.5～16.0kHz
The magnitude of carry frequency ties up the noise of motor running. The carry frequency is
generally set upward 6 kHz to manage to travel without noise. To the best of noise allowing
range, reduce the carry frequency
When the carrier frequency is low, the output current higher-harmonic component increases,
the consumption and
temperature rise of the motor increase as well.
When the carrier frequency is high, the motor consumption declines and the motor temperature
rise reduces, but the consumption, temperature rise and interference of the system increase.
To regulate the carrier frequency will exert inuences on the following performances:
Carrier Frequency Low～High
Motor noise Large～Small
Output Current Wave Form Bad～Good
Motor Temperature Rise High～Low
System Temperature Rise Low～High
Leakage Current Small～Large
External Radiation Interference Small～Large
6.2 F1 Group Motor Parameters
Function code Name Default Min. Unit Setting Range
F1-00
Selection of
encoder’s type
1model 1
0: SIN/COS
1:UVW
The parameter is invalidation for the asynchronous motor. For synchronous motor UVW selects
1, ERN1387 SIN/COS encoder selects 0.
