11：Run monitor:
NICE 3000 is in running state.
12：Synchronous motor auto-run:
It’s the self-locking contactor to control permanent-magnet synchronous motor. If the
synchronous motor is in self-running emergency when the lift is in power failure emergency
running state, the brake open, the corresponding terminal output, lift slip into the nearest
leveling land and open door. Details are in chapter 7
, user introduction. In addition, it can be
used after the lift stops in normal condition to enhance safety.
13：Power failure emergency running efficiency:
When lift is in power failure emergency running state, the corresponding terminal will output.
Details are in chapter 7, adjusting explanation.
14：System normal:
When the system is in normal work condition, the corresponding terminal will output.
This
function can be used for parallel or group control.
15: Emergency buzzer output
It will indicate the leveling condition when it’s in emergency condition.
16: Brake forced output
Open the brake and last 4s each time; it can be used to control the starting voltage of the
brake.
17. Elevator up marks
18. Fan and light output
Terminals to output the fan and light signals, it is same as fan and light si
ngal of car top board.
Function code Name Default Min. Unit Setting Range
F5-32 Hall call condition display
When users enter F5-31 menu, the tube on the keyboard shows the output terminal state at
present. The keyboard tube order is 5, 4,3,2,1 from left to right. Every passage’s definition is
as follows:
The meaning of each passage is listed in the following charts:
