NICE3000 User Manual Function parameter description
139
Current station: It reects the absolute position of the car to the leveling plate of the rst oor.
The unit is M.
Car load: according to the information from the sensor, its the percentage of car load to rated
load, with the unit %.
Car top input state: It shows the meaning by bit. If the bit is 1, the signal is valid. There is
16 bit whose meanings are as follows:
Binary bit Meaning Binary bit Meaning
Bit0 Front light curtain input Bit8 Door-open button input
Bit1 Back light curtain input Bit9 Door-close button input
Bit2 Front door-open limit Bit10
Door-open delay button
input
Bit3 Back door-open limit Bit11 Non-stop button input
Bit4 Front door-close limit Bit12 Motorman button input
Bit5 Back door-close limit Bit13 Vary direction button input
Bit6 Digital load 3 (full load) Bit14 Separ
ately running button input
Bit7 Digital load 4 (over load) Bit15 Fire button input
Car top output state: It shows the meaning by bit. If the bit is 1, the signal is valid. There is
16 bit whose meanings are as follows:
Binary bit Meaning Binary bit Meaning
Bit0 Front door-open output Bit8 Door-open button display
Bit1 Front door-close output Bit9 Door-close button display
Bit2 Door lock signal Bit10
Door-open delay button
display
Bit3 Back door-open output Bit11 Non-stop button display
Bit4 Back door-close output Bit12 Motorman signal
Bit5 Door lock signal Bit13 Vary direction signal
Bit6 Up arrival gong Bit14 Separately running signal
Bit7 Down
arrival gong Bit15 Fireman operation signal
System state: It shows the meaning by bit. If the bit is 1, the signal is valid. There is 16 bit
whose meanings are as follows:
Binary bit Meaning Binary bit Meaning
Bit0 System light curtain state 1 Bit8 Car state:
1: door open;
2: door open keeping;
3: door close
4: door open limit
5: running
Bit1 System light curtain state 2 Bit9
Bit2 External call lock lift Bit10
Bit3 External call re Bit11
