NICE3000 User Manual System typical application and adjustment
169
function codes need setting:
Function code Name Setting Range Setting when parallel
F5-29 Y4 function selection 0~14 14
7.5.3 Parallel lifts case instruction
After the two lifts are in parallel, when the stopping position of the two lifts is different, the lifts
external call dial is different from that of single lift running. When the lift adjustment is completed
and gets into the parallel function adjustment step, generally conne
ct the parallel wiring
according to the former description and set the car top dial code and main control board output
setting. But in some special condition, special disposal is needed. Several typical examples are
listed in the following, and it can exibly apply according to the examples.
For example: Suppose that there are two lifts in parallel, the No.1 lift stops at Floor B1, Floor
1, Floor 2
, and Floor 3; the No. 2 lift stops at Floor 1, Floor 3, and Floor 4; Now the two lifts are
both setting parallel according to section 7.5.1 and 7.5.2. The required special setting is listed
as follows:
Floor dial code setting, display setting
When two lifts are in parallel, if the oor structure is different, the counting of the
oor is according to the lowest oors minimum value to the highest oors maximum value,
and corresponding dial code is according to the lowest oors minimum value, cumulated by
the physical oor. The overlapped service oor zone still needs install leveling plate in the shaft
even if the lift doesnt stop at
this oor. Set the service oor to make the lift doesnt stop at
this oor. In the example, Floor 1 and Floor 3 are in the overlapped service oor zone, but No.2
lifts Floor 2 doesnt have the oor door, which means it doesnt serve the Floor 2, but this
oor still needs install leveling plate.
The corresponding setting of No.1 lift:
1 2 3 4 8 Physical oor Display setting
B1 ON OFF OFF OFF ON 1 FE-01=1101
1 OFF ON OFF OFF OFF 2 FE-02=1901
2 ON ON OFF OFF OFF 3 FE-03=1902
3 OFF OFF ON OFF OFF 4 FE-04=1903
The corresponding setting of No.2 lift:
1 2 3 4 8 Physical oor Display setting
1 OFF ON OFF OFF ON 2 FE-02=1901
2 Not service, but must installation leveling plate FE-03 =1902
3 OFF OFF ON OFF OFF 4 FE-04=1903
4 ON OFF ON OFF OFF 5 FE-05=1904
Bit of
DIP
State
Floor
Bit of
DIP
State
Floor
