NICE3000 User Manual Structure of the control system and the component introduction
31
X1
X2
X3
X4
CN3
P24
P24
X5
X6
X7
X8
BM
B1
B2
B3
CM
C1
C2
C3
DM
D1
D2
CN4
24V
MOD
+
MOD
-
COM
CN1
24V
CAN
+
CAN
-
COM
CN2
A
AM
CN5
P24
Ai
M
CN6
CN7
Fig 3-2 Denition of CTB terminals
Explanation of controlling terminals function 3)
Type
Terminal
designation
Terminal name Functional explanation
Power
24V
(CN1CN2
terminals)
Connect to +24V external power
source
Provide+24Vpower for whole
board as Operational Power
Supply
COM
(CN1CN2
terminals)
Connect externally to common
port
P24
(other terminals)
+24V power supply
Common port of digital input
and analog input
Function digital input
X1 Font door beam screen
Photocoupler isolation
unipolar
ity input
Input impedance3.3KΩ
MCTC-CTB signal is valid when
inputting 24V power supply
X2 Back door beam screen
X3 Font door open limit
X4 Back door open limit
X5 Front door-close limit
X6 Back door-close limit
X7 Full load signal (100%)
X8 Over load signal (110%)
Analog input Ai-M Weighing signal input DC010V
