Structure of the control system and the component introduction NICE3000 User Manual
36
Sequence
number（n）
Corresponding
interface
Definition Instruction
17 JP17 Door opening button input
Invalid for command board 2
18 JP18 Door closed button input
19 JP19 Door opening delay button input
20 JP20 Nonstop button input
21 JP21 Motorman button input
22 JP22 Reversing direction button input
23 JP23 Running independently button input
24 JP24 Fireman input
Light output:b)
sequence
number（n）
corresponding
interface
definition explanation
1 JP1 Floor 1show output
Input signal corresponds
to oor(16+n) display for
command board 2
2 JP2 Floor 2 show output
3 JP3 Floor 3 show output
4 JP4 Floor 4 show output
5 JP5 Floor 5 show output
6 JP6 Floor 6 show output
7 JP7 Floor 7 show output
8 JP8 Floor 8 show output
9 JP9 Floor 9 show output
10 JP10 Floor 10 show output
11 JP11 Floor 11 show output
12 JP12 Floor
12 show output
13 JP13 Floor 13 show output
14 JP14 Floor 14 show output
15 JP15 Floor 15 show output
16 JP16 Floor 16 show output
17 JP17 Door opening show output
I
nvalid for command board 2
18 JP18 Door closed show output
19 JP19 Door opening delay show output
20 JP20 Nonstop show output
Cautions:
In order to protect communication signals from external disturbance, we advise to use

STP for communication connection;
Con
nect strictly according to terminal signal, and insert the button firmly;

The two terminals of the command board are the same interface apparatus, so when in

parallel connection of the command board, pay attention not to wrongly connect.
