6-66 ENGINE GENERAL INFORMATION AND DIAGNOSIS (TBI FOR G10)
INSPECTION
STEP ACTION YES NO
1 Was “ENGINE DIAG. FLOW TABLE” performed? Go to Step 2. Go to “ENGINE
DIAG. FLOW
TABLE”.
2 Is there DTC(s) other than fuel system
(DTC P0171/P0172)?
Go to applicable
DTC Diag. Flow
Table.
Go to Step 3.
3 Check HO2S-1 Output Voltage.
1) Connect scan tool to DLC with ignition switch OFF.
2) Warm up engine to normal operating temperature and keep
it at 2000 r/min. for 60 sec.
3) Repeat racing engine (Repeat depressing accelerator pedal
5 to 6 times continuously and take foot off from pedal to
enrich and enlean A/F mixture). See Fig. 1.
Does HO2S-1 output voltage deflect between below 0.3 V and
over 0.6 V repeatedly?
Go to Step 4. Go to DTC
P0130 Diag.
Flow Table
(HO2S-1 circuit
check).
4 Check Fuel Pressure (Refer to section 6E1 for details).
1) Release fuel pressure from fuel feed line.
2) Install fuel pressure gauge.
3) Check fuel pressure. See Fig. 2.
With fuel pump operating
and engine at stop : 160 – 210 kPa, 1.6 – 2.1 kg/cm
2
,
22.7 – 29.9 psi.
At specified idle speed : 90 – 140 kPa, 0.9 – 1.4 kg/cm
2
,
12.8 – 20.0 psi.
Is measured value as specified?
Go to Step 5. Go to Diag. Flow
Table B-3 Fuel
Pressure Check.
5 Check Fuel Injectors and Circuit.
1) Turn ignition switch OFF and disconnect fuel injector
connector.
2) Check for proper connection to fuel injector at each terminals.
3) If OK, then check injector resistance. See Fig. 3.
Injector resistance: 0.5 – 1.5 Ω at 20_C (68_F)
Go to Step 6. Check injector
circuit or replace
fuel injector.
4) Connect injector, connector.
5) Check that fuel is injected out in conical shape from fuel
injector when running engine.
6) Check injector for fuel leakage after engine stop.
Fuel leakage: Less than 1 drop/min.
Is check result satisfactory?
6 Check EVAP Canister Purge Valve.
1) Disconnect purge hose (1) from EVAP canister.
2) Place finger against the end of disconnected hose.
3) Check that vacuum is not felt there when engine is cool and
running at idle. See Fig. 4.
Is vacuum felt?
Check EVAP
control system
(See Section
6E1).
Go to Step 7.
7 Check intake manifold absolute pressure sensor for
performance (See DTC P0105 Diag. Flow Table).
Is it in good condition?
Go to Step 8. Repair or
replace.
To Next Page
