ENGINE GENERAL INFORMATION AND DIAGNOSIS (SFI FOR G13) 6-1-83
INSPECTION
STEP ACTION YES NO
1 Was “ENGINE DIAG. FLOW TABLE” performed? Go to Step 2. Go to “ENGINE DIAG.
FLOW TABLE”.
2 Check Short Term Fuel Trim.
Did short term fuel trim vary within –20% –+20%
range in step 3) of DTC confirmation test?
Go to Step 3. Check fuel system.
Go to DTC P0171/P0172
Diag. Flow Table.
3 Check HO2S-2 for Output Voltage.
Perform steps 1) through 9) of DTC confirmation
procedure for DTC P0136 (HO2S-2 malfunction)
and check output voltage of HO2S-2 then.
Is over 0.6 V and below 0.3 V indicated?
Replace three way
catalytic converter.
Check “R” and “G” wires
for open and short, and
connections for poor
connection.
If wires and connections
are OK, replace
HO2S-2.
To Next Page
