7B-4 AUTOMATIC TRANSMISSION (3 A / T) (VEHICLE WITH WU-TWC)

COMPONENTS OPERATION CHART

Range Gear

Forward

Clutch

Direct

Clutch

Second

Brake

1st & Reverse

Brake

One-way

Clutch

Parking Lock

Pawl

P Parking – – – **f** – f

R Reverse – f – f – –

N Neutral – – – – – –

1st f – – – f –

2nd f – f – – –

3rd f f – – – –

1st f – – – f –

2nd f – f – – –

1st f – – f f –

*2nd f – f – – –

f: Operated

*: To prevent over-revolution of engine, this 2nd gear is operated only when selector lever is shifted to L range

at a higher than 37 km/h (23 mile/h) (G10 engine model), 40 km/h (25 mile/h) (G13 engine model) speed.

**: When engine is running.
