4-18 FI SYSTEM DIAGNOSIS
FI SYSTEM TROUBLESHOOTING
CUSTOMER COMPLAINT ANALYSIS
Record details of the problem (failure, complaint) and how it occurred as described by the customer. For this
purpose, use of such an inspection form such as below will facilitate collecting information required for
proper analysis and diagnosis.
EXAMPLE: CUSTOMER PROBLEM INSPECTION FORM
User name: Model: VIN:
Date of issue: Date Reg. Date of problem: Mileage:
FI indicator light condition
Always ON Sometimes ON Always OFF Good condition
PROBLEM SYMPTOMS
Difficult Starting Poor Driveability
No cranking Hesitation on acceleration
No initial combustion Back fire/ After fire
No combustion Lack of power
Poor starting at
( cold warm always)
Surging
Abnormal knocking
Other Engine rpm jumps briefly
Other
Poor Idling Engine Stall when
Poor fast Idle Immediately after start
Abnormal idling speed
( High Low) ( r/min)
Throttle valve is opened
Throttle valve is closed
Unstable Load is applied
Hunting ( r/min to r/min) Other
Other
OTHERS:

Suzuki TU250X Specifications

General

Displacement	249 cc
Bore x Stroke	72.0 mm x 61.2 mm
Compression Ratio	9.2:1
Ignition	Electronic ignition (transistorized)
Starter	Electric
Transmission	5-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Swingarm type, coil spring, oil damped
Rear Brakes	Drum brake
Front Tire	90/90-18 M/C 51S, tube type
Rear Tire	110/90-18 M/C 61S, tube type
Overall Length	2070 mm (81.5 in.)
Overall Width	750 mm (29.5 in.)
Overall Height	1075 mm (42.3 in.)
Seat Height	770 mm (30.3 in.)
Ground Clearance	165 mm (6.5 in.)
Wheelbase	1375 mm (54.1 in.)
Curb Weight	148 kg (326 lbs.)
Engine Type	4-stroke, single cylinder, SOHC
Front Brakes	Single disc
Fuel Capacity	12 L (3.2 US gal.)
