6-2 EXHAUST SYSTEM
EXHAUST SYSTEM
REMOVAL


• Remove the right frame cover. (8-3)
• Remove the bracket bolt 1 and disconnect the HO2 sensor
coupler 2.
• Remove the muffler cover 3.
: Hooked part
• Remove the exhaust pipe bolts 4.
To avoid the danger of being burned, do not touch the
exhaust system when the system is hot. Any service
on the exhaust system should be performed when the
system is cool.
Make sure that the exhaust pipe and muffler have
enough clearance from the rubber parts and plastic
parts to avoid melting.

Suzuki TU250X Specifications

General

Displacement	249 cc
Bore x Stroke	72.0 mm x 61.2 mm
Compression Ratio	9.2:1
Ignition	Electronic ignition (transistorized)
Starter	Electric
Transmission	5-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Swingarm type, coil spring, oil damped
Rear Brakes	Drum brake
Front Tire	90/90-18 M/C 51S, tube type
Rear Tire	110/90-18 M/C 61S, tube type
Overall Length	2070 mm (81.5 in.)
Overall Width	750 mm (29.5 in.)
Overall Height	1075 mm (42.3 in.)
Seat Height	770 mm (30.3 in.)
Ground Clearance	165 mm (6.5 in.)
Wheelbase	1375 mm (54.1 in.)
Curb Weight	148 kg (326 lbs.)
Engine Type	4-stroke, single cylinder, SOHC
Front Brakes	Single disc
Fuel Capacity	12 L (3.2 US gal.)
