PERIODIC MAINTENANCE 2-21
EXHAUST PIPE BOLTS AND MUFFLER
MOUNTING BOLTS
Tighten the exhaust pipe bolts, muffler connecting bolt and muf-
fler mounting bolts to the specified torque.
 Exhaust pipe bolt 1: 23 N·m (2.3 kgf-m, 16.5 lbf-ft)
Muffler connecting bolt 2: 23 N·m (2.3 kgf-m, 16.5 lbf-ft)
Muffler mounting bolt (Front) 3: 23 N·m (2.3 kgf-m, 16.5 lbf-ft)
Muffler mounting bolt (Rear) 4: 50 N·m (5.0 kgf-m, 36.0 lbf-ft)
Tighten initially at 1 000 km (600 miles, 3 months) and
every 10 000 km (6 000 miles, 30 months) thereafter.

Suzuki TU250X Specifications

General

Displacement	249 cc
Bore x Stroke	72.0 mm x 61.2 mm
Compression Ratio	9.2:1
Ignition	Electronic ignition (transistorized)
Starter	Electric
Transmission	5-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Swingarm type, coil spring, oil damped
Rear Brakes	Drum brake
Front Tire	90/90-18 M/C 51S, tube type
Rear Tire	110/90-18 M/C 61S, tube type
Overall Length	2070 mm (81.5 in.)
Overall Width	750 mm (29.5 in.)
Overall Height	1075 mm (42.3 in.)
Seat Height	770 mm (30.3 in.)
Ground Clearance	165 mm (6.5 in.)
Wheelbase	1375 mm (54.1 in.)
Curb Weight	148 kg (326 lbs.)
Engine Type	4-stroke, single cylinder, SOHC
Front Brakes	Single disc
Fuel Capacity	12 L (3.2 US gal.)
