AMI CACE
Default Values
Case temp. high:......................................................................65 °C
Case temp. low: .........................................................................0 °C
Relay 1/2 Function: .......................................................................... limit upper
Parameter: ...................... Relay 1: Cond 1(sc), Relay 2: Cond 2(cc)
Setpoint:.............................................................................. 1000 µS
Hysteresis: .............................................................................. 10 µS
Delay:.....................................................................................30 Sec
If Function = Control upw. or dnw:
Parameter: ...................... Relay 1: Cond 1(sc), Relay 2: Cond 2(cc)
Settings: Actuator: ...........................................................Frequency
Settings: Pulse Frequency:................................................ 120/min.
Settings: Control Parameters: Setpoint: ............................. 1000 µS
Settings: Control Parameters: P-band: ................................... 10 µS
Settings: Control Parameters: Reset time: ..............................0 Sec
Settings: Control Parameters: Derivative Time:.......................0 Sec
Settings: Control Parameters: Control Timeout: ..................... 0 Min.
Settings: Act. Time prop.: Cycle time: ....................................... 60 s
Settings: Act. Time prop.: Response time: ................................ 10 s
Settings: Act. Motor valve: Run time: ........................................ 60 s
Settings: Act. Motor valve: Neutral zone: ....................................5%
If Function = Timer:
Mode: Interval: ........................................................................ 1 min.
Mode: daily/weekly: ......................................Starting time: 00.00.00
Run time: ...............................................................................10 Sec
Delay:.......................................................................................5 Sec
Signal output:............................................................................ cont.
Output/Control: .......................................................................... cont
Input: Active ............................................................................when closed
Signal Outputs ........................................................................... hold
Output/Control ..............................................................................off
Fault..............................................................................................no
Delay......................................................................................10 Sec
