1 GENERAL
1.1 Range of Application
The COMPACT Unit and COMPACT Top are complete air
handling units with built-in control equipment. The air
handling units are designed for comfort ventilation and
can be utilised in smaller buildings such as offices, schools,
day nurseries, public buildings, shops and residential build-
ings.
The COMPACT Unit air handling units have duct connec-
tion spigots on their end panels whereas the COMPACT
Top units have them at the top. The type of unit can
therefore be selected on the basis of the amount of space
available for installing it and for arranging the ducts.
The COMPACT Unit and COMPACT Top are one-piece air
handling units. If supplementary function sections such as
dampers and air coolers are required, they must be in-
stalled in the ductwork.
In order to fully obtain all the benefits the COMPACT
system has to offer, it is important keep in mind the air
handling unit’s special characteristics in conjunction with
designing the project, installing the unit, adjusting it and
operating the system.
The unit must be installed indoors.
Important!
Always read the safety precautions in Section 2 that
explain the risks involved in running the unit and
designate who shall be permitted to operate and
service the unit, and carefully follow the installation
instructions provided in each paragraph.
The product identification plate is situated on the top of
the air handling unit. Refer to the particulars on the prod-
uct identification plate when you contact Swegon.
1.2 Mechanical Design
The COMPACT is available in one physical size and for two
airflow ranges.
The external sheet metal surfaces of the unit are painted
white, NCS S 0502-G, except for the rear of the COM-
PACT Top unit which consists of an aluminium-zinc plated
sheet steel casing panel..
The upper section of the junction hood of the COMPACT
Unit is light grey, NCS S3502-B and the lower section is
dark grey, NCS S6010-R90B.
The inner skin is predominantly made of aluminium-zinc
plated sheet steel. The casing has 30 mm thick intervening
mineral wool insulation; the inspection doors have 50 mm
thick insulation.
The COMPACT Unit and the COMPACT Top are equipped
with pleated, Class F7 filters.
The type RECOnomic rotary heat exchanger is variable
speed controlled and has a temperature efficiency of up to
85%.
The supply air and extract air fans are direct-driven plug
fans. The fans are equipped with EC motors that provide
high efficiency across the entire operating range.
1.3 Control System
The IQnomic control system is microprocessor-based and is
integrated into the unit. It controls and regulates the fans,
heat exchanger, temperatures, airflows, operating times
and a large number of internal and external functions as
well as alarms.
1.4 Environmental Documentation
Environmental Documentation with the Dismantling
Instructions for Recycling and the Environmental Product
Declaration can be downloaded from our website: www.
swegon.com.
The air handling unit is designed in such a way that it can
be dismantled into its natural parts for scrapping. When
the unit has ended its useful product life, the services of
an accredited recycling company should be utilised for
disposal.
Approximately 94% of the parts in COMPACT air handling
units are recyclable.
Swegon AB is associated with the REPA Register, No.
5560778465.
Contact Swegon AB, Phone: +46 (0)512-322 00, if you
have any questions regarding the dismantling instructions
or the air handling unit’s impact on the environment.
