Swegon COMPACT Unit - Internal Connections

GB.COMPACTUT.170622
Registered design. The company reserves the right to make design changes without prior notice.
www.swegon.com 57
20.3.1 Internal Connections
Control unit
Red
Yellow
Black
Brown
Blue
Black
Heat exchanger motor
Rotation monitor sensor
32-36 V AC from transformer
18 V AC from transformer
24 V AC from transformer
Temperature sensor, outdoor air
Temperature sensor, extract air
Pressure sensor, extract air fan
Pressure sensor, supply air fan
Sensor, supply air
temperature
Communication, hand-held
micro terminal
PE LN LNPE
201 202
3A
Power unit
Yellow/Green
Extract air fan
Blue
Brown
Blue
Yellow/Green
Brown
Supply air fan
Yellow
Yellow
Transformer
Yellow/Green
Blue
Brown
Cable, 230 V power supply
Red
Green
Brown
Blue
Orange
Violet
Air heater (accessory).
VOC sensor, TBLZ-60 (accessory)
Red
Brown
Black
230 control voltage, output
