GB.COMPACTUT.170622
Registered design. The company reserves the right to make design changes without prior notice.
46 www.swegon.com
INSTALLATION
15 COMMUNICATION
Provision for communication and supervision is
integrated as standard into the COMPACT. The unit
is ready to be connected via EIA-485 and Ethernet.
For particulars of connecting and wiring the air
handling unit, see Section 20.3.2 Wiring to Termi-
nals.
Communication can also be established via Ether-
net without software other than an ordinary web
browser such as Internet Explorer.
Further information about interfaces, proto-
col and configuration is available at www.
swegon.se (com) under Products/Air handling
units/COMPACT air handling units/Documen-
tation.
15.1 EIA-485
Protocol and settings for EIA-485 is specified.
Settings:
Value Setting range
Modbus RTU Address, speed, parity, stop bits
Metasys N2 OPEN
Lon Works
Exolinc
15.2 Ethernet
Protocol and settings for Ethernet is specified.
Settings:
Value Setting range
Ethernet MAC ID
DHCP SERVER
(active or inactive)
IP ADDRESS
(static or dynamic)
SUBNETM.
GATEWAY
DNS-SERVER
MODBUS TCP CLIENT
(IP address, netmask and port
number)
BACNet IP
(active or inactive, Device ID,
Port no.)
COMMUNICATION
*COMMUNICATION*
EIA-485
ETHERNET
INSTALLATION
SERVICE LEV.
*SERVICE LEV.*
CODE:0000
16 SERVICE LEVEL
A code and special training are required for access to this
menu group.
