Alarm No.:
Function
Factory preset value Adjusted value
Priority Indication Effect Priority Indication Effect
0=blocked LED 0=Operat. 0=blockedt LED 0=Operat.
A=A alarm 0=Off 1=Stop A=A alarm 0=Off 1=Stop
B=B alarm 1=On B=B alarm 1=On
92 Frost prot. for preheating sensor, faulty A 1 1
93 Preheating sensor faulty A 1 1
94 Electric air heater for preheating, tripped A*** 1 1
95 Preheating below setpoint A*** 1 1
96 Lost settings A 1 1
99 Time lock tripped A 1 1
102 Cooling valve I/O-7 defective B*** 1 0
103 Heating valve I/O-7 defective A*** 1 0
104 Cool. circuit pump I/O-7 tripped B*** 1 0
105 Heat. circuit pump I/O-7 tripped A*** 1 1
106 Cooling water temp. I/O-7 below set point B*** 1 0
107 Heat. water temp. l I/O-7 below set point A*** 1 0
108 Cooling water temp. I/O-7 above set point 0*** 1 0
109 Heating water temp. I/O-7 above set point 0*** 1 0
110 Cooling water temp. sensor I/0-7 defective B 1 0
111 Heating water temp. sensor I/0-7 defective A 1 0
* Not adjustable, always stops the air handling unit
** Not adjustable, stops the air handling unit at temperature below +5 °C
*** Blocked if the hand terminal does not display the main menu.
**** Cannot be blocked.
Adjustments carried out by:
Date
Company
Name
