12. BODY COVER
12-4
Side Covers
1. Removal:
y Remove 2 screws (front/middle) from two
side covers.
y Slide the side cover backward so that
their hooks are out of slots.
y Take out the side cover end part and then
remove the cover.
2. Installation:
y Install in reverse order of removal
procedures.
Caution
The tail of each cover is held with buckles and
slot, never pull them with force, or it would
crack the buckles.
Screws
