12. BODY COVER
12-13
Under Cover
1. Removal:
y Remove the right and left side cover.
y Remove 2 bolts from the under cover.
y Remove under cover.
2. Installation:
y Install in reverse order of removal
procedures.
2 bolts
2 bolts
