2. SERVICE MAINTENANCE INFORMATION
2-1
General Information··························2-1
Periodical Maintenance Schedule···2-2
Air Cleaner ········································2-3
Fuel Lines··········································2-3
Fuel Filter ··········································2-4
Engine Oil Line ·································2-4
Oil Pump Control Cable ···················2-5
Tire·····················································2-6
Battery ···············································2-6
Rear Brake Free Play: (Drum Brake Type)
····························································2-7
Brake System Hose: (Front Disc Brake
Type)··················································2-8
Steering System································2-10
Suspension····································· 2-10
Transmission Oil···························· 2-11
Spark Plug ······································ 2-11
Control Cable Lubrication ············· 2-12
Driver Belt······································· 2-12
Ignition Timing ······························· 2-12
Throttle Valve Operation················ 2-12
Carburetor Idle Speed Adjustment 2-13
Carbon Removing For Exhaust Pipe &
Muffle ·············································· 2-13
Cylinder Compression Pressure Test
2-13
Headlight Adjustment···················· 2-14
General Information
Specification
Tire dimension
Front: 3.00-10 42J
Rear: 3.00-10 42J
Tire pressure at cold Only rider
Front: 1.5kg/cm
2
Rear: 2.25 kg/cm
2
Front brake lever free play 10~20 mm
Rear brake lever free play 10~20 mm
Transmission oil Recommendation
Type: HYPOID GEAR OIL
Oil: SAE #140
Quantity: 0.1 L
Spark plug Recommendation
Type: NGK BR8HSA
Plug gap: 0.6-0.7mm
Driving belt width
Standard 18.0mm
Allowable limit: replace it if below 16.5mm
Ignition timing F mark
17°, BTDC/1500 rpm
Acceleration operation 2~6 mm
Idle speed
2000±100 rpm
Cylinder compression pressure
7±1 kgf/cm²
2
