2. SERVICE MAINTENANCE INFORMATION
2-5
Oil Pump Control Cable
Caution
To adjust the oil pump control cable after
adjusted the throttle grip play.
Remove the body cover.
Wide open the throttle valve, and check if the
calibration point aligns on the oil pump lever with
the mark of pump body.
Loosen the adjustment nut of the oil pump control
cable.
Turn the adjustment nut and align with the point,
then tighten the nut.
Mounting nut
Adjustment nut
