12. BODY COVER
12-9
Front under Spoiler
Removal:
y Remove the front cover and right / left
side cover.
y Remove 4 screws from the front inner
box.
y Remove 2 screws from the front upper
part of the front spoiler and the front inner
box.
y Remove front wheel bolt and wheel.
y Remove 2 screws from the lower part of
the front spoiler.
y Remove the front spoiler.
2. Installation:
y Install in reverse order of removal
procedures.
Screws
Bolt
Screw
Screw
