15. ELECTRICAL EQUIPMENT
15-1
Maintenance Information ················ 15-2
Troubleshooting ······························ 15-3
Battery ·············································· 15-4
Charging System ····························· 15-5
Ignition System ································ 15-9
Starting System ······························ 15-12
Oil Level Switch ······························ 15-14
Fuel Unit ·········································· 15-15
Switch/Horn····································· 15-16
Bulb Replacement ·························· 15-18
15
Spark Plug
AC. Generator
Fuse Box
Battery
IG. Coil
Fuel Unit
Main Switch
Reg. Rec. Comp
Start / Headlight Switch
Start Relay
Horn
Horn / Winker /
Dimmer Switch
Resistor Comp
Winker Relay
CDI Unit
Oil Level Switch
