1. GENERAL INFORMATION
1-9
High/low beam switch
Horn switch
Rear brake lamp switch
Winker switch
Speedometer
Headlight switch
Starter switch
Throttle cable
Headlight
Rear brake cable
Speedometer cable
Throttle cable
Main switch
Regulator
Resistor
Horn
Front brake cable
Speedometer cable
Front brake cable
Winker relay
Front brake
lamp switch
Winker light
