9. FINAL DRIVING MECHANISM
9-1
Mechanism Diagram ··························· 9-1
Precautions in operation ···················· 9-2
Trouble Diagnosis······························· 9-2
Disassembly of Final Driving Mechanism
······························································ 9-3
Inspection of Final Driving Mechanism
······························································· 9-4
Bearing Replacement ·························· 9-5
Re-assembly of Final Driving Mechanism
······························································· 9-8
Mechanism Diagram
9
Final shaft
Final gear
Counter gear
Counter shaft
Drive shaft
1.0~1.4kgf-m
Bearing (6301)
Bearing (6004)
Bearing (CSB301)
Bearing (6004)
Bearing (6301)
Bearing (6204)
