12. COOLING SYSTEM
12-1
Mechanism Diagram ··························12-1
General Information ···························12-2
Trouble Diagnosis······························12-2
Trouble Diagnosis for Cooling System
·····························································12-3
System Test········································ 12-5
Radiator ·············································· 12-6
Water Pump········································ 12-8
Thermostat ········································· 12-12
Mechanism Diagram
Radiator filler cap
Radiator
Reserve tank
Thermo switch (fan)
Radiator filler cap
Reserve tank
Thermo switch (fan)
Coolant inlet pipe Coolant outlet pipe By-pass pipe
Thermo unit (temp meter)
Water pump
Thermostat
12
Cooling fan
Cooling fan
