17. ELECTRICAL SYSTEM
17-1
Mechanism Diagram ··························17-1
Maintenance Data·······························17-2
Technical Specification······················17-2
Trouble Diagnosis······························17-3
Battery·················································17-4
Charging System································17-5
Ignition System···································17-8
Starting System··································17-10
Meters················································17-11
Light / Bulb········································17-12
Switch / Horn·····································17-14
Fuel Unit············································17-17
Cooling Fan Thermo Switch ············17-18
Thermo Unit ······································17-19
Water Temperature Meter ················17-19
Mechanism Diagram
Winker relay
Spark plug
AC. Generator
Fuse box
Battery
Ignition coil
Fuel unit
Main switch
C.D.I. unit
Regulator rectifier
Starter relay
Start switch & light switch
Horn
Dimmer & winker & horn switch
Headlight relay
