16. REAR WHEEL / REAR FORK / REAR CUSHION
16-1
Mechanism Diagram ··························· 16-1
Operational Precaution······················· 16-2
Trouble Diagnosis······························· 16-2
Muffler················································· 16-3
Rear Wheel ········································· 16-3
Rear Cushion······································ 16-5
Mechanism Diagram
3.5~4.5kgf-m
1.0~1.2kgf-m
3.2~3.8kgf-m
10.0~12.0kgf-m
2.4~3.0kgf-m
16
4.0~5.0kgf-m
