13. BODY COVER
13-13
Front fender
Remove
Remove right & left front fender B. (4 bolts)
Upward pushes, after causes the tenon to fall off
front, again takes out the front fender B.
Caution
y When disassemble age must pay attention,
whether the tenon is separated from.
y Cannot hardly pull out, is easy to create the
tenon to break off.
Remove speedometer cable. (1 screw)
From front fender left side remove brake pipe clip.
4 bolts
1 screw
Brake pipe position
