11. CRANKCASE / CRANK
11-1
Mechanism Diagram ··························11-1
General information ···························11-2
Trouble diagnosis ······························11-2
Disassembly of crankcase ················ 11-3
Crankshaft Inspection ······················· 11-5
Assembly of crankcase····················· 11-6
Mechanism Diagram
1.5~3.0kgf-m
1.0~1.5kgf-m
0.8~1.2kgf-m
1.2~1.6kgf-m
11
