5. ENGINE REMOVAL
5-4
Remove the mounting bolt of right-rear cushion.
Remove the rear fork mounting bolt. (2 bolts)
Remove rear wheel mounting nut.
Remove rear fork and collars.
Remove rear wheel.
Remove the mounting bolt of left-rear cushion.
2 Bolts
Rear wheel axle nut
Left-rear cushion bolt
