SYMEO LPR-1DHP User Manual

SYMEO Local Positioning Radar System
LPR-1DHP
Product Documentation
Overview of the LPR-1DHP system
Copyright © Symeo GmbH 2012
Page 11 of 40
2.3 Mounting position of the LPR-1DHP stations
The stations must be aligned with each other for proper measurement. In addition the
following topics must be considered:
 Site-specific mounting instructions must be followed when available.
 A minimum distance of 2 meters between the two system units must be maintained to
guarantee the specified accuracy.
 Minimum distance of 50 cm between adjacent systems must be used to avoid cross-
interference.
 The two system units must be mounted opposite to each other with less than 10 cm
horizontal or vertical offset.
 The stations must be aligned with an accuracy better than +/- 2°.
 The orientation of the stations must be the same, e.g. both units with LED-display
oriented to the roof or to the same wall.
