SYMEO LPR-1DHP User Manual

SYMEO Local Positioning Radar System
LPR-1DHP
Product Documentation
Web Server for LPR-1DHP units with TCP/IP interface
Copyright © Symeo GmbH 2012
Page 25 of 40
Connection Type Area
Disabled
The port is „Disabled“ and not be reachable via TCP/IP.
TCP – Variable Frame –
Listening on Data Port
The LPR-1DHP station is waiting for incoming connection on
the “Data Port”. If the connection is opened successful you
can open the binary port. „Variable Frame“ means activated
„Byte Stuffing“ (no fixed protocol length).
TCP – Variable Frame –
Connecting to Data Port
The LPR-1DHP station establishes the connection to the
entered server IP-address. Setting “Random” means both
communication partners arrange the reverse channel
autonomously. If the connection is opened successful you
get access to the binary port. „Variable Frame“ means
activated „Byte Stuffing“ (no fixed protocol length).
TCP – Fixed Frame –
Listening on Data Port
The LPR-1DHP station is waiting for an incoming connection
on the “Data Port”. If the connection is opened successfully
you can open the binary port. „Fixed Frame“ means
deactivated „Byte Stuffing“ (fixed protocol length).
TCP – Fixed Frame –
Connecting to Data Port
The LPR-1DHP station establishes the connection to the
entered server IP-address. Setting “Random” means both
communication partners arrange the reverse channel
autonomously. If the connection is opened successful you
get access to the binary port. „ Fixed Frame“ means
deactivated „Byte Stuffing“ (fixed protocol length).
UDP – Fixed Frame –
Sending to Data Port
The LPR-1DHP station sends and receives data (UDP) to
and from the entered server IP-address. The reverse channel
uses also the data port. „Fixed Frame“ means deactivated
„Byte Stuffing“ (fixed protocol length).
7.2.4 „Remote Access“ Area
Telnet
Click this checkbox to allow or prevent console accesses to port 23 via
Telnet (checked: accesses are allowed). The port number is not editable.
See also section "Extended system access".
SSH/SCP/SFTP
Click this checkbox to allow or prevent console accesses to port 22 via
SSH (Secure SHell and data transmission via SCP (Secure CoPy) or
SFTP (Secure File Transfer Protocol) (checked: accesses are allowed).
The port number is not editable. See also section "Extended system
access".
HTTP
Click this checkbox to permit or forbid accesses to the LPR-1DHP station's
Web server via HTTP (unencrypted transmission) (checked: accesses are
allowed). You must also enter the corresponding port number as
appropriate. The port number is set to 80 (http protocol standard) by the
manufacturer.
HTTPS
Click this checkbox to permit or forbid accesses to the LPR-1DHP station's
Web server via HTTPS (encrypted transmission) (checked: accesses are
allowed). You must also enter the corresponding port number as
appropriate. The port number is set to 443 (http protocol standard) by the
